BT-AUTO H15 LED Headlight Bulb All In One Plug and Play High Beam DRL LED H15 CANBUS Headlight Bulb Factory

Short Description:

We sell BT-AUTO H15 LED Headlight Bulb All In One Plug and Play High Beam DRL LED H15 CANBUS Headlight Bulb Factory

We are professionally engaged in auto LED Headlight, LED bulbs, HID, etc for years.

Welcome OEM and ODM.

Applications: VW, AUDI, BEM, BENZ, FORD, PEUGEOT, CITROEN, FIAT, SEAT, etc..

Voltage-in: DC 9-16V/high beam, DC 6-16V/DRL(6V start)

Power: 20W(high beam) / 5W(DRL)

Lumen: 2500LM(high beam), 400LM(DRL)




Product Detail

LED chips 2 * 7545 LED module + 2 * ZES LED chip
Voltage-in DC 9-16V/high beam, DC 6-16V/DRL(6V start)
Current-start 2.0(high beam) / 0.4A(DRL)@12V
Power 20W(high beam) / 5W(DRL)
Lumen 2500LM(high beam), 400LM(DRL)
Working temperature -40℃~+80℃
Power efficiency >87%
Beam angle 270°
Color temperature 6000K
CANBUS CANBUS inside
Cooling type Fan
Adapter Plug & Play
Life span 30000+ hours
Warranty 12 months
Lighting pattern High beam + DRL

Application:

VW Golf MK6 6 VI 2009-2011; VW Golf MK7 7 VII 2012-2016; VW Tiguan 2012-2016; VW Scirocco 2008-2012; Ford Fiesta MK9 9; Ford Kuga 2013-2016; Audi A3 S3 8V 2012-2016; Audi A3 S5 2010-2012; Audi A6 S6 C7 2012-2016; Audi Q7 2010-2016; BMW 2 Series: F22 F23 2014-2016; Seat Alhambra 710 2010-2016; Citroen Jumper 252 2011-2016; Mercedes Benz GLK Class: X204 2013-2016; Mercedes Benz A W176; Mercedes Benz CLA C117; Mazda 6 2013, 2014-2016; Peugeot Boxer 252 2011-2016; Fiat Ducato 252 2011-2016, etc.

Original design:

All in one design led headlight bulb, integrated aluminum body; Original lighting mode: high beam(with reflecting cap) + DRL(6V start); Original integrated 3 PIN socket: plug & play.



7545 Lattice power LED module + ZES Lumileds LEXEON LED chip:

Similar size as halogen bulb, high beam chip and DRL chip are separate; Reflector cap for high beam; 6V start for DRL.



High Power & Lumen & LUX:

High power: 20W(high beam) / 5W(DRL); High lumen: 2500LM(high beam), 400LM(DRL),

High lux: 3-5 times than halogen.



Good Lighting Pattern:

Same design as halogen bulb: High beam chip and DRL chip are separated, reflector cap for high beam, 6V start for DRL.

Efficient heat conduction & dissipation system:

High quality aluminum PCB for good heat conduction; Imported hydraulic fan for cooling.



Plug & Play 3 PIN socket:

Original 3 PIN socket, same as halogen; No extra wire between bulb and socket; Plug and play.



Built-in driver:

Voltage input: DC 9-16V/high beam, DC 6-16V/DRL; DRL function: 6V start; Driver built-in; CANBUS built-in: solving most canbus problems.



Dimensions:

diameter φ30mm, height 88mm, width 19mm



Package:

Soft box: 145*134*65mm, 2pcs/set; Customized is accepted.

Welcome OEM and ODM for all BT-AUTO LED Headlight

20191020-H15F (1) 20191020-H15F (2) 20191020-H15F (3) 20191020-H15F (4) 20191020-H15F (5) 20191020-H15F (6) 20191020-H15F (7) 20191020-H15F (8) 20191020-H15F (9) 20191020-H15F (10) 20191020-H15F (11) 20191020-H15F (12)
