BT-AUTO CSP-4 Car LED Bulb Light T20 S25 9005 H11 Fog Lamp LED Turning Reversing CANBUS LED Tail Bulb Lamp

Short Description:

We are selling BT-AUTO CSP-4 Car LED Bulb Light T20 S25 9005 H11 Fog Lamp LED Turning Reversing CANBUS LED Tail Bulb Lamp.

We have built constant business relationships with customers from Russia, Europe, North America, South America and so on. We are looking forward to cooperating long term business with you.

Available models: T20(7440, 7443), T25(3156, 3157), S25(1156, 1157), FOG.

Current: 0.84A/T20,T25.S25, 0.94A/FOG

Voltage: 9-30V

Available color: white, yellow, amber, red


Product Detail

Type automotive led bulb
Current 0.84A/T20,T25.S25, 0.94A/FOG
Power 1.5W/T10, 6.6W/T15/T16
Lumen l60lm/T10, 660lm/T15
Voltage 9-30V
PCB superconducting aluminum substrate
Available color white yellow amber red
Polarity Non-polarity
Life span 30000+ hours
Warranty 12 months
MOQ 50pcs
Certificate CE, RoHS
Function turning, reversing, braking, DRL FOG, light.
Car fitment universal, can use on cars like Toyota, Honda, Nissan, Mazda, KIA, Hyundai, BENS, BMW, Audi, Citroen, Peugeot, FORD, BUICK, Chevy, etc.

Structure:

CSP3570 customized LED chip; Aluminum heat sink body; Built-in intelligent driver; Aluminum double sides PCB; High quality socket.



CSP3570 customized LED chip:

CSP3570: 15W/pc, 115lm/W; Customized LED chip with lens, unique, goods focus and lighting pattern.



Double sides aluminum PCB:

Thin PCB for better lighting pattern; High heat-conduction, much better than normal glass fiber board PCB; Good electrical insulation performance and high mechanical strength.



Aluminum Body:

Aviation level aluminum alloy; Precise CNC machining, excellent heat-conduction; Large heat sink surface area, superior cooling performance.



Socket:

Original adapter, standard and small; High strength, high insulation, anti-corrosion,

PIN is phosphor copper with gold plating, phosphor copper is good electric conduction and ductility, gold plating is anti-oxidant and elegant, wider and stronger PIN; Easy installation with the long wire cable; Plug and Play.



Driver:

Stable and efficient; Constant current; High quality SMD components.



Lighting:

Available color: white, yellow. Amber, red; High lumen: 1100LM/white, 1000LM/A, 960LM/A, 250LM/R; Beam angle: 360°; Good lighting pattern.



Testing:

We have integrating sphere tester and other professional testing machines; All products in the order will be tested before ship out.



Installation:

easy installing, plug and play, fits for almost all cars; CAN connect an extra resistor If have canbus problem, like error on dash board, fickler, etc.

Warranty: take video of the problem to replace new or refund.



Package:

Blister package: elegant, blister is sealed with high frequency plastic welding machine; Box package: supereme, high-end; Customized package is accepted.

CSP-4详情 (1) CSP-4详情 (2) CSP-4详情 (3) CSP-4详情 (4) CSP-4详情 (5) CSP-4详情 (6) CSP-4详情 (7) CSP-4详情 (8) CSP-4详情 (9) CSP-4详情 (10) CSP-4详情 (11) CSP-4详情 (12) CSP-4详情 (13)
