BT-AUTO X6 36W Super Bright AUTO LED Headlight Bulb LENS Projector Car LED CANBUS 12V 24V Headlight

Short Description:

We supply BT-AUTO X6 36W Super Bright AUTO LED Headlight Bulb LENS Projector Car LED CANBUS 12V 24V Headlight.

We have been specializing in AUTO LED headlight and car LED bulbs for years. We have built constant business relationships with customers from many countries. We expecting become your long-term business partner in China.

Weclome OEM and ODM

Voltage-in: DC 9-18V / 18-40V

Power: 36W

Lumen: 2800LM


Product Detail

Type LED Headlight
LED chips 2 * Lattice power 7545 LED module
Voltage-in DC 9-18V / 18-40V
Current-start 3.0A@12V
Power 36W
Lumen 2800LM
Working temperature -40℃~+80℃
Power efficiency >87%
Beam angle 270°
Color temperature 6500K
CANBUS CANBUS inside
Cooling type Fan
Temperature control Intelligent temperature control IC (built-in driver)
Adapter 360°adjustable
Life span 30000+ hours
Car make universal
Warranty 12 months
Lighting pattern Low beam / High beam

Brand new design:

Triangle patent design, unique for projector / LENS headlight; Copper PCB; Rubber ring & fixing screw for 360°adjustable adapter.



7545 Lattice power LED module chip:

Bigger size than halogen filament, brighter & wider lighting pattern.



High Power & Lumen & LUX:

High power: 36W; High lumen: 2800LM; High lux: 5-7 times than halogen.



Good Lighting Pattern:

For projector/LENS headlight: no dark area for low beam, brighter focus, wider extension.

X6 LED Headlight is only for low beam projector/lens headlight kit



Efficient heat conduction & dissipation system:

Copper PCB for better heat conduction than aluminum; Imported hydraulic fan for cooling.

Smart 360°adjustable adapter:

H7, D2/D4: the adapter is fixed by triple rubber rings, and is easily rotated in 360°,

H8/H9/H11/H16(JP), 9005, 9006, 9012, D1/D3: there is a tiny screw for fixing adapter.

Small size driver:

Voltage input: DC 9-18V(for cars) / 18-40V(for trucks); CANBUS built-in: solving most canbus problems; Intelligent temperature control IC built-in: the current will drop gradually when the intelligent Temperature Control IC(built-in base) reaches 120°C; Non-polarity; No electromagnetic interference; Size: 52.5*26*16mm; Laser logo is accepted.

Thin top body & Small base:

Diameter Φ15mm of top body, fitting for more vehicles; Diameter Φ36mm of base, fitting for more vehicles.

Soft box: 201*138*75mm, 2pcs/set,

Carton box: 52*44*35 cm, 28sets/carton; Customized is accepted.

Welcome OEM and ODM for all BT-AUTO LED Headlight bulbs.
